The Future of Backplanes

NO RATINGS
View Comments: Newest First | Oldest First | Threaded View
ChristophZ
User Rank
Author
Re: Embedded coax in PCB
ChristophZ   1/9/2014 1:58:01 AM
NO RATINGS
All I know is what this company says they can manufacture: www.variooptics.com

rick merritt
User Rank
Author
Re: Future low loss PCB di-electric material
rick merritt   1/7/2014 2:08:35 PM
NO RATINGS
Eric: I'd love to see at the February event the 2014 update of that "Most Importnat Slide"

I'd also love to hear your insights on the question of new materials and transports like Megtron-6 and optics.

Sanjib.A
User Rank
Author
Future low loss PCB di-electric material
Sanjib.A   1/6/2014 11:26:30 AM
NO RATINGS
"The difference, however, is less than an order of magnitude."


Megatron6 is one of the future PCB dielectric material. Is it commercially deployed yet? How does the cost of Megatro6 compares to that of FR4?

Some time back I learned Megatron6 is only one in the list of several other low loss PCB dielectric material such as FX-2, I-speed (from Isola) etc. Is there a comparative chart available somewhere?

Sanjib.A
User Rank
Author
Re: Embedded coax in PCB
Sanjib.A   1/6/2014 11:06:00 AM
NO RATINGS
What about the concept of using the optical PCB and interconnects for the high speed backplane? Not sure if there are any significant breakthrough made on the optical PCB technology.

_hm
User Rank
Author
Embedded coax in PCB
_hm   1/5/2014 11:08:51 AM
NO RATINGS
When you have mutliple HSS, is it possible to get embedded coax in PCB. Are there technics available for this? Main reason is that, high speed signal is only part of all signals and there are many more signals which requires backplane.
