Why a Little Ringing in Step Load Isn’t Such a Little Problem
8/14/2013

< Previous   Image 3 of 4      Next >

Figure 3: Step load response on LT1009 voltage reference with a 0.1uF capacitor.  Note the drastically different responses related to the higher and lower current levels.  Also note the complex harmonic structure that includes each of the two ringing frequencies and all of the mixing products between these frequencies and the repetition rate of the step load, which is 3kHz in this example.
Figure 3: Step load response on LT1009 voltage reference with a 0.1uF capacitor. Note the drastically different responses related to the higher and lower current levels. Also note the complex harmonic structure that includes each of the two ringing frequencies and all of the mixing products between these frequencies and the repetition rate of the step load, which is 3kHz in this example.

< Previous   Image 3 of 4      Next >

Return to Article

View Comments: Newest First | Oldest First | Threaded View
Steve.Picotest
User Rank
Author
Re: Um...
Steve.Picotest   8/15/2013 4:16:21 PM
NO RATINGS
The simple version is that while a little ringing looks like one frequency it is really in fact many frequencies.  These all contribute to circuit noise and so a little ringing equals a lot of noise.



Thanks for reading and for taking the time to comment



Steve.Picotest
User Rank
Author
Does this topic "resonate" with you (sorry, but couldn't resist)
Steve.Picotest   8/14/2013 5:25:14 PM
NO RATINGS
Please let me know if you have seen stability problems that degraded circuit performance or feel free ask any questions you might have about how to solve such problems.  I do like opportunities to talk with all of you
