True White LEDs on the Horizon

9/17/2013 05:24 PM EDT
12 comments
NO RATINGS
More Related Links
View Comments: Oldest First | Newest First | Threaded View
Page 1 / 2   >   >>
_hm
User Rank
CEO
Good for high CRI
_hm   9/17/2013 7:09:29 PM
NO RATINGS
This is a wonderful news for white LEDs. What kind of CRI will it achieve? Also improving efficuency near 50% is huge advantage to all this green movement cool LED lamps.



R_Colin_Johnson
User Rank
Blogger
Re: Good for high CRI
R_Colin_Johnson   9/17/2013 7:38:30 PM
NO RATINGS
Its too early to start measuring CRI, but he researchers next goal is to tune their platinum-rich polymer to have a very high CRI. We'l have to wait about a year to find out just how high.

daleste
User Rank
CEO
Re: Good for high CRI
daleste   9/17/2013 9:58:01 PM
NO RATINGS
Interesting technology.  Any chance of obtaining the same results with other metals?  Seems like everything we do requires expensive raw materials.

R_Colin_Johnson
User Rank
Blogger
Re: Good for high CRI
R_Colin_Johnson   9/17/2013 10:36:45 PM
NO RATINGS
I asked them the same question, and they said that any "heavy" metal might enable this polymer to be both fluorescent and phosphorescent, platinum was just the best candidate. And in the next phase of their research they plan to try out others.

Kinnar
User Rank
CEO
It has shown positive results but actual white LED is yet to come
Kinnar   9/18/2013 6:52:31 AM
NO RATINGS
The research has shown a very positive results in terms of efficiency and colour control, but infact this will still require many to find out the real white out of it. As none of the experiments have resulted in a white colour outputing LED. If a cheap metal can replace platinun it can be really an affordable light.

LarryM99
User Rank
CEO
What about brightness and power efficiency?
LarryM99   9/18/2013 7:41:54 PM
NO RATINGS
It seems like a major growth field for LEDs is automotive applications, particularly headlights. Are these as bright and power-efficient as current technologies? Do they last as long as well?

Cost is also a consideration. I see expensive metals, but how much does that translate into increased cost per unit?

R_Colin_Johnson
User Rank
Blogger
Re: What about brightness and power efficiency?
R_Colin_Johnson   9/18/2013 11:01:33 PM
These researchers are shooting for OLED applications--backlights, light bulb replacements and such. They also claim their approach will be lower cost, because of the extreme simplicity of their design--no pixels or phosphors, but its too early to say whether longevity will be enhanced too.

Jack.L
User Rank
CEO
Re: Good for high CRI
Jack.L   9/18/2013 11:27:36 PM
NO RATINGS
White is "white" no matter how achieved. That said I don't really see how their design is "whiter" than other white LEDs with multiple band-gaps that create overlapping spectrums that add up to white. Effectively that is all they are doing. It just sounds like academic double-speak, not to downplay the accomplishment.

One of the posters talked about getting past 50%. We are already there. State of the art white LED (blue pumped phosphor) are already at or greater than 50% wall plug efficiency. The blue die on its own is hitting 60%.

_hm
User Rank
CEO
Re: Good for high CRI
_hm   9/19/2013 6:44:21 PM
NO RATINGS
That is very good news about high efficiency. But CRI needs to be 95 or better.



Jack.L
User Rank
CEO
Re: Good for high CRI
Jack.L   9/19/2013 7:17:21 PM
NO RATINGS
Why? There is really no justification for that at all.

Without intimate knowledge of a scene and that same scene having lots of red, most people would not be able to tell if the light source was 85 or 95CRI. Side by side comparison, maybe, but without a reference no.

CRI is not a great measurement of color fidelity anyway. CRI is only a measure effectively of how well a light source either matches a blackbody radiator at some CCTs and sunlight at others. Given the vast amount of 4000K lighting, there is no blackbody reference comparison or sunlight for that matter than anyone could really make.

You can make lower CRI sources look better than high CRI sources depending on the color gamut, and spectral pattern.

If you want to mimic an incadenscent bulb perfectly great, but the prevalence of 2700-3000K sources in terms of evolutionary biology are pretty near nil. Even when sunlight is in the CCT range, it does not look blackbody.

Page 1 / 2   >   >>
