Kinnar
User Rank
CEO
Re: Inexpensive test gear
Kinnar   12/25/2013 1:57:06 PM
NO RATINGS
You are right but I think NI, MyRio also finds a better place as compared to all others listed out there. Here is the link to it.

NI myRIO is an embedded hardware device designed to design real, complex engineering systems it simultaneously allows to test and measure many protocols as well on an FPGA.



Sanjib.A
User Rank
CEO
Re: Inexpensive test gear
Sanjib.A   12/25/2013 10:43:17 AM
NO RATINGS
Thank you! :)

David Ashton
User Rank
Blogger
Re: Inexpensive test gear
David Ashton   12/25/2013 5:18:23 AM
NO RATINGS
@Sanjib - I am hoping to get an Analog Discovery next year and if I do I will try and let you know how it goes.  Everything I have heard about them has been good.  Anyone else have hands-on experience with them?

Sanjib.A
User Rank
CEO
Re: Inexpensive test gear
Sanjib.A   12/25/2013 3:26:37 AM
NO RATINGS
@David Ashton:

Great to learn about "Analog Discovery" from Digilent. Thanks!! Looks to be a professional product for low speed lab work and handy for debugging as it is multipurpose: oscilloscope cum logic analyzer cum multimeter. Ease of portability makes it good to place the tool on the desk instead the requirement for a lab space. Requesting your comments after you get a chance to try that.

David Ashton
User Rank
Blogger
Inexpensive test gear
David Ashton   12/24/2013 7:29:28 PM
NO RATINGS
Hi Susan, and Happy Christmas.

I think any list like this ought to mention two more items:

1. The National Instruments MyDAQ

NI gear is usually pretty expensive (as is the LabView software needed to drive it) but if you are a student you can get their MyDAQ, which is intended for student use and is cheap ($99 for students with a copy of LabView), but it is only 200 KSPS  / 20KHz bandwidth which I find woefully inadequate - even the low range items above do 2 MSPS and 200 KHz Bandwidth.  Nevertheless it is a versatile goodie - has digital I/O and a DMM built in - and quite good value if you're a student.

2. Digilent Analog Discovery

Digilent make the Analog Discovery which is $99 if you can get the student price, a bit more otherwise.  100 MSPS 14-bit channels and they claim effective 5 MHz bandwidth - plus digital I/O.  I'd like to get one of these - streets ahead of the MyDaq.

Both of these are USB/PC based, so no good if you want something standalone.Both are intended for the educational area, but still useful for low speed lab work.
